Learn the Art and Science of PCB Design with Eagle

You will design your first PCB within 20 minutes of enrolling to the course If electronics is your passion, read out!!! Are you electronics hobbyist? Are you a student studying electronics for...

  • All levels
  • English

Course Description

You will design your first PCB within 20 minutes of enrolling to the course If electronics is your passion, read out!!! Are you electronics hobbyist? Are you a student studying electronics for the first time? Are you crazy to know about all those open source schematics on the internet and wonder how these are designed? This course is about learning circuit design with Autodesk Eagle, whic...

You will design your first PCB within 20 minutes of enrolling to the course If electronics is your passion, read out!!! Are you electronics hobbyist? Are you a student studying electronics for the first time? Are you crazy to know about all those open source schematics on the internet and wonder how these are designed? This course is about learning circuit design with Autodesk Eagle, which is the most popular design tool used by millions of people around the world. If you have ever came across any open source hardware like Arduino, its designed with eagle, if yo have seen those crazy nice modules and kits developed by Sparkfun, they are designed with eagle. Eagle has became de-facto language of the PCB design in the open source world and thereby in the industry.

What you’ll learn
  • Anyone who wants to learn PCB Design
  • Electronics engineering students and school students
  • Professionals who want to start PCB designing
  • Startups finding difficult to get PCB designed for their products
  • Those willing to learn PCB Design without buying a costly software

Covering Topics

1
Section 1 : Introduction

2
Section 2 : Software Installation and Creating First project

3
Section 3 : Library and Schematic

4
Section 4 : Single Sided PCB Design

5
Section 5 : Single Sided PCB Design Hands on

6
Section 6 : Creating PCB Project

7
Section 7 : Copper Pour

8
Section 8 : Double Sided PCB Design

9
Section 9 : All about SMT Components

10
Section 10 : Create Custom Library Component in Eagle

11
Section 11 : Using Autorouter (Cheating the Software!!!)

12
Section 12 : Copy frequently required parts in your library

13
Section 13 : Manufacturing Guide

14
Section 14 : Conclusion

Curriculum

      Section 1 : Introduction
    1
    Introduction to Course Preview
    2
    Basics of Printed Circuit Board (Important)
      Section 2 : Software Installation and Creating First project
    3
    Eagle Software Installation Preview
    4
    Creating Project With Eagle
      Section 3 : Library and Schematic
    5
    Creating Schematic With Eagle Preview
    6
    Eagle Installing External Libraries Preview
      Section 4 : Single Sided PCB Design
    7
    Create First Complete Schematic in Eagle
    8
    First PCB Layout, the proper placement of component
    9
    Create First Single Sided PCB with Eagle
    10
    Adding Name and Labels to Eagle Schematics
    11
    Layers in Eagle
      Section 5 : Single Sided PCB Design Hands on
    12
    Single Sided PCB Hands on assignment files
      Section 6 : Creating PCB Project
    13
    Microcontroller PCB Project with Eagle Part 1
    14
    Microcontroller PCB Project with Eagle Part 2
    15
    Microcontroller PCB Project with Eagle Part 3
      Section 7 : Copper Pour
    16
    Adding Copper Pour to Eagle PCB
      Section 8 : Double Sided PCB Design
    17
    Double Sided PCB Design with Eagle
    18
    Double Sided PCB Design ( Hands On)
      Section 9 : All about SMT Components
    19
    Surface Mount Devices in Eagle
    20
    SMT based Schematic (FTDI Project)
    21
    SMT and Double Sided PCB Design
      Section 10 : Create Custom Library Component in Eagle
    22
    Eagle Create Custom Library Part 1
    23
    Eagle Create Custom Library Part 2
    24
    Eagle Create Custom Library Part 4
      Section 11 : Using Autorouter (Cheating the Software!!!)
    25
    Use Autorouter for single sided PCB
    26
    Use Autorouter for Double sided PCB
      Section 12 : Copy frequently required parts in your library
    27
    Copy frequently required parts in your library
      Section 13 : Manufacturing Guide
    28
    Print a Single Sided PCB Preview
    29
    Gerber File Extraction
    30
    Generate Bill Of Materials
      Section 14 : Conclusion
    31
    Conclusion
